Summary
• Temperature : 80°C.
• Rated voltage : 2000Volts.
• Horizontal flame.
•Test probe lead for electrical and electronic measuring .
| UL1803 | ||||
| Wire Size | Conductor | Insulation | Overall | |
| Construction | Resistance | Thickness | Diameter | |
| AWG | No./mm | Ω/km | mm | mm |
| 26 | 7/0.16 | 139.73 | 1.15 | 2.78 |
| 24 | 11/0.16 | 93.3 | 1.15 | 2.91 |
| 22 | 17/0.16 | 55 | 1.15 | 3.06 |
| 20 | 26/0.16 | 34.6 | 1.15 | 3.24 |
| 18 | 41/0.16 | 21.8 | 1.15 | 3.48 |
