UL1015

UL1015

• Conductor : Solid or stranded, tinned or bare copper , 30-2AWG.
• lnsulation : Lead Free PVC.
• Insulatior : 2000VAC/min.

Inquiry
Please refer to the "Inquiry List" on Contact Us.

Summary

• Temperature : 105℃.
• Rated voltage : 600Volts.
• For general purpose internal wiring of electrical, and electrical equiment.
• Uniform thickness of wire to ensure easy stripping and cutting.

UL1015　　　　
Wire Size Conductor Insulation
Construction Resistance Thickness O.D
AWG No/mm Ω/Km mm mm
26 7/0.160 152 0.76 2.08
24 11/0.160 88.6 0.76 2.2
22 17/0.160 62.5 0.76 2.4
20 21/0.180 39.5 0.76 2.6
18 34/0.180 24.4 0.76 2.8
16 26/0.254 15.6 0.76 3.1
14 41/0.254 9.9 0.76 3.5
12 65/0.254 6.24 0.76 4.1
10 105/0.254 4.15 0.76 5.1
24 7/0.200 88.6 0.76 2.2
22 7/0.254 62.5 0.76 2.4
20 7/0.254 39.5 0.76 2.6
18 7/0.400 24.4 0.76 2.8
24 1/0.511 92.4 0.76 2.15
22 1/0.643 60.1 0.76 2.3
20 1/0.813 37 0.76 2.45
18 1/1.020 23.6 0.76 2.72
