Summary
• Temperature : 80°C.
• Rated voltage : 300Volts.
• Passes UL VW-1 & CAS FT1 vertical flame test.
• Internal wiring or external interconnection of electronic equipment.
| UL2464 | ||||||
| Wire Size | Conductor | Core | Insulation | Jacket | Overall | |
| Construction | Resistance | Thickness | Thickness | Diameter | ||
| AWG | No./mm | Ω/km | mm | mm | mm | |
| 26 | 7/0.16 | 140 | 3 | 0.38 | 0.76 | 4.6 |
| 4 | 4.95 | |||||
| 5 | 5.35 | |||||
| 24 | 11/0.16 | 87.6 | 3 | 0.38 | 0.76 | 4.95 |
| 4 | 5.3 | |||||
| 5 | 5.75 | |||||
| 22 | 17/0.16 | 55.4 | 3 | 0.38 | 0.76 | 5.25 |
| 4 | 5.7 | |||||
| 5 | 6.15 | |||||
| 20 | 21/0.16 | 34.6 | 3 | 0.38 | 0.76 | 5.7 |
| 4 | 6.15 | |||||
| 5 | 6.7 | |||||
| 18 | 34/0.16 | 21.8 | 3 | 0.38 | 0.76 | 6.25 |
| 4 | 6.75 | |||||
| 5 | 7.35 | |||||
