Summary
• Temperature : 80℃.
• Rated voltage : 600Volts.
• Pass UL FT2 Horizontal flame test.
• Internal Wiring of Appliances where exposed to temperatures not exceeding 80 deg C; or Internal Wiring of Appliances where exposed to temperatures not exceeding 80 deg C or where exposed to oil at a temperature not exceeding 60 deg C or 80 deg C (whichever is applicable).
| UL1018 | ||||||
| Wire Size | Conductor | Core | Insulation | Jacket | Overall | |
| Construction | Resistance | Thickness | Thickness | Diameter | ||
| AWG | No/mm | Ω/Km | mm | mm | mm | |
| 8 | 168/0.251 | 2.16 | 1 | 1.14 | 0.05 | 6.9 |
| 6 | 124/0.37 | 1.39 | 1 | 1.14 | 0.05 | 8 |
